Introduction
What is a cellular confinement system?
Essentially, a three-dimensional geosynthetic structure that resembles a flexible honeycomb, a cellular confinement system enhances the performance of soil, aggregate and other infill materials once it is expanded and filled to create a stable layer that helps “contain” the material under loading, on slopes and in areas subject to water flow.
In the geocell world, this product is commonly referred to as a geocell, though it may also be identified as a cellular confinement system, honeycomb geocell, HDPE (high density polyethylene) geocell, slope protection geocell, erosion control geocell, load support system, base stabilization, retaining wall geocell, channel protection, and more.
Key Explanation
Made from strips of polymer material (typically HDPE), a cellular confinement system is formed by welding the strips together to make panels. When expanded on-site, the three-dimensional grid or panels create a “honeycomb” formed by “cells.” Finally workers fill them with soil, gravel, sand, crushed stone, or even concrete, depending on the application.
The confinement effect is the major advantage. Without such confinement, aggregate can experience horizontal movement due to pressure. With geocell confinement, the aggregate is locked into place. This produces better shear strength, less material movement, and greater load-bearing capacity for the base.
This is one reason geocells are used in roads, as well as ground reinforcement, slope protection, or erosion control in locations where soft soil and/or steep grades, as well as heavy traffic, creates problems for conventional fill.
For projects where you need a reliable reinforcement layer, a properly designed geocell system may provide the answer.
Find out more on our Product Page (Geocell), or browse our Category Page, or send us your drawings via our Contact / Get quote page.
Applications / Use Cases
Cellular confinement systems are frequently used in civil engineering and site development.
For roads and access ways, geocell is frequently employed for base stabilizaton and load support. It distributes wheel loads over a wider area, minimizing rutting and extending the life of pavement making it a robust alternative for driveways, temporary roads, parking areas, construction entrances, and weak subgrade.
For slopes, a slope protection geocell locks soil in place and mitigates erosive forces on the surface. When filled with top soil and vegitation, it provides a greener slope protection. In more robust conditions, when filled with gravel or concrete, it can withstand harsher treatment as well as weighting runoff.
For correspondance, channel protection geocell is used to withstand scouring forces of flowing water. It shoould be used in ditch linings, at the toe of embankments, as well as for canal and spillway protection, or anywhere confinement is needed to keep rapid water action from washing away the infill material.
For retaining structures, a retaining wall geocell can be used to contain and improve upon soil layers behind. Found often in landscaping, and in road shoulders on infrastructure development.
For environmental and land reclamation work, erosion control geocell is used to lock down exposed soil after grading and earth works.It can mitigate surface loss on a rainy day, and help achieve a long-term ground cover.
Common applications include:
- Driveway geocell projects
- Road base stabilization
- Slope protection and embankment support
- Channel Protection, ditch lining
- Retaining wall support
- Heavy-load platforms
- Parking lots and access roads
Comparison or Benefits
In comparison to using loose aggregate alone, a cellular confinement system has some obvious benefits.
The first is in improved lateral restraint. The aggregate inside each cell cannot move whatsoever, as freely making it much more stable as it takes the load from traffic or a stream.
The second benefit of using a cellular confinement system is that of load distribution. Instead of being in one area all the pressure is being spread by the whole of the cellular layer.
In some instances the designer can save aggregate use by a geocell layer, in using smaller thickness, but still getting good performance from it.
On slopes or channels the infill is kept in place by restraint and so helps a great deal with preventing the washout of the soil.
Finally the cellular structure (geocell) is versatile. A high strength geocell can be used with disparate materials where necessary. E.g., Different materials for infilling in accordance with project requirement. Some systems are textured and perforated and those offer better friction and also drainage, although geocell and other non-perforated geocell options may be used elsewhere.
A practical comparison is, if the loose fill is like a pile of stones, the solution is like giving the stones a framework.The framework is designed to help them act as one consolidated layer.
How to choose/buy
Requirements for the right cellular confinement system depend on project conditions, level of loading, and installation environment.
Start by looking at the application. A driveway or light traffic area may call for a standard load support system, a steep slope or water channel for a heavier material, a deeper cell height or perforation pattern.
Next is the height of each cell. Geocell height determines how deep the confinement is, and the effectiveness of the overall structure. Cells that are higher will provide an increasingly improved level of restraint for thicker layers of infill, but the right height is a function of the design and the expected load.
Material quality also matters. The majority of buyers opt for HDPE geocell because it is durable enough to resist weathering for long term outdoor use.
You should also consider whether it is a perforated and textured product, or non-perforated. Barriers to drainage may be reduced and the interface with neighbouring material improved with a perforated design. A textured surface can enhance stability and improve resistance to relative movement.
Welding method is another consideration. As they tend to have cleaner seams and superior manufacturing quality, ultrasonic welding geocell products can often be trusted more. If sourcing from a geocell manufacturer or geocell supplier, ask about raw material, welding strength, size of each panel, dimensions of cells and references from similar projects.
When comparing options, focus on:
- Project load and soil condition
- Slope angle or channel water flow
- Required offset height
- HDPE material quality
- Cut space or no cut space design
- Supplier experience and production standard of geocells
- Price per square metre and delivery lead time
And when you actually buy geocell, whether online or otherwise, do not focus only on price. A low price is of little use if the product does not meet the requirement of the project and help to bring it to code. The right system is the one that matches site condition and delivers stable performance as anticipated.
FAQ
What is a cellular confinement system?
A three-dimensional geosynthetic product that confines the material that will fill the connected cells within for improved stability, load support and erosion resistance.
How does it work?
It will expand into a honeycomb type arrangement. Once the cells are filled with soil, gravel, or other material, the geocell reduces the tendency for materials to move laterally and causes the load to be dispersed more effectively.
What is the cost/lifespan?
The cost will vary depending on cell height, the thickness of the material supplied, the size of the project, surface treatment, etc. Lifespan will depend on exposure to UV light, the quality of preparation and installation, and site condition. A properly made HDPE geocell can offer long service life in civil engineering applications.
What is the best option?
The best option will vary from project to project. As for roads and driveways, they mostly require a load support system or a base stabilization geocell. As for slopes channels, a design made for erosion control or channel protection is preferable.
What are the common issues?
The common issue here would be selecting the wrong height of cells, poor infill, weak subgrade preparation, or a product not suited to the site condition. Installation quality is also very important.
